Novus Digitermo DTL-DN32 Ultrasonic Heat Meter

Novus Digitermo DTL-DN32 Ultrasonic Heat Meter

• Novus Digitermo DTL ultrasonic heat meter
• Body size DN32 (1¼”), nominal flow rate Qn 6 m³/h
• Body length (L) 180 mm, 1½” threaded connection
• Communication: Wired M-Bus
• Application: heating and cooling; installation point: return line
• Temperature sensor: Standard PT1000
• MID approval: Türkiye, accuracy class 2
• Pressure rating: PN16

Novus Digitermo DTL Series

Novus Digitermo DTL is an ultrasonic heat meter manufactured and MID-approved in Türkiye; it measures heating and cooling energy in buildings with central heating.

The meter consists of a calculator unit, an ultrasonic flow sensor and a PT1000 temperature sensor pair. It is installed in the return line and read remotely via wired M-Bus.

Key Features (manufacturer data)

• MID approved (Türkiye), accuracy class 2 (EN 1434)
• Heating and cooling measurement
• Wired M-Bus communication
• Medium temperature 5–90 °C, temperature difference 3–75 K; pressure rating PN16
• Protection class IP65
• Made in Türkiye

Applications

• Large apartments, duplexes and office floors
• Commercial units and shops
• Sub-distribution lines within buildings
• Heat cost allocation and energy monitoring

Why Novus Digitermo DTL?

Digitermo DTL is a series made in Türkiye, selected for use with Novus Energy's meter reading and heat cost allocation infrastructure; metering, reading and billing are handled by a single provider.

Installation, Reading and Re-verification

Install the meter in the position and at the mounting point specified in its manual; a strainer upstream of the meter and an isolating valve before and after it (for easy replacement) are recommended. In Türkiye, Novus Energy also provides remote meter reading and heat cost allocation services after installation. Periodic re-verification requirements for heat meters depend on local regulations; see our re-verification and calibration page for details.
